KNOCKS
Made in Germany
MPN 9.1123.00.400, G 1/2 auto drain.
Technical Specifications
| Port size | G 1/2 |
| Medium | Compressed air; neutral gases |
| Description | Centrifugal force principle with sintered filter |
| Mounting | Vertically, drain plug at bottom |
| Supply pressure | Pe max.16 bar (also with automatic drain) Pe max. 25 bar with metal bowl Pe min. 1,5 bar with semi- and auto drain |
| Filter element | 40 μm standard |
| Media and ambient temperature | Max. 60℃ (oth. temperature ranges available upon request) |
| Bowl volume | Max. 50cm³ condensation volume |
| Drain model | Manual drain standard |
| Fixing | Bracket |
