TOGNELLA
PRESSURE SWITCHES
FT-P27HP300 R14 SS 20-300bar, 1/4"BSPP
Made in Italy
Technical Specifications
| Switch rating | 250 V DC |
| Max. current | 0,5 Amp (resist) |
| Electrical contact | SPDT |
| Max. static pressure | 600 bar |
| Adjusting range | 20-300 bar |
| Operating temperature | -20℃ to 110 ℃ |
| Max. working frequency | 30 min |
| Electrical protection | IP65 |
| Hysteresis | ~15% of setting point |
| Operating time tollerance | ~8% of setting point |
| Mechanic life | 10^6 cycles |
| Electrical lift | 10^5 cycles |
| Gasket | NBR |
| Piston | Steel |
| Electrical connection | Silver plated |
| Body material | AVP Zinc plated steel |
| Plastic head | Nylon 6/6 fv.30 |
